Order picking trolley

Order picking trolley with 200 kg shelf load – inclinable, non-marking, for tough warehouse operations

High load capacity – even for heavy order picking items

Each shelf supports 200 kg, and the solid bottom base is designed for up to 500 kg. This means the order picking trolley is suitable not only for light small parts containers but also for heavy boxes, toolboxes, or large items. All shelves are made of weather-resistant screen printing plate – non-slip, moisture-resistant, and suitable for outdoor use.

Inclinable shelves with 10 mm rim in a 50 mm grid

• Height adjustable in a 50 mm grid – adaptable to any container and storage size
• Inclinable up to 15° – contents slide forward automatically, always within reach
• 10 mm rim on all shelves – goods are securely held, no slipping off
• Support frame made of steel hollow section – torsion-resistant and permanently dimensionally stable

Non-marking elastic rubber castors – gentle on hall floors

The castors are equipped with non-marking elastic rubber – they leave no abrasion marks on epoxy resin, PVC, or concrete floors. Ideal for production and storage halls where clean floors are a must. Two swivel castors with brakes ensure secure fixation at any workstation.

4 basic sizes, 3 heights, 3 surfaces

• Loading areas: 850×500 / 1000×600 / 1000×700 / 1200×800 mm
• Heights: 1200 / 1500 / 1800 mm
• Painted – economical standard version for dry indoor areas
• Powder-coated – increased corrosion protection, any RAL colors
• Hot-dip galvanized – for outdoor use and humid environments

Matching accessories

For longer transport routes or larger halls, we recommend the order picking trolley with drawbar – same features, additionally with a tow bar for tractor or manual operation.
